BAR-TEK 2.0 TSI EA888 GEN4 MQB ULTIMATE HIGH BOOST ENGINE KIT

Our best parts designed for the new Evo4 engines such as in the Golf 8 GTI, R, Audi S3 and many others.

This kit is made for you if you are serious about improving performance. Our ULTIMATE kit includes everything to make you and your engine happy: power up to 1000 HP with your 2.0L TSI engine!

Perfectly tuned: 2.0-liter TSI ULTIMATE kit for performance up to 1000 HP

Whenever you think more isn""t possible, think about this kit. Because here we have outdone ourselves once again. The ULTIMATE kit isn""t called that for nothing! Here you have everything you need for the best performance with your 2.0L STI: a perfect combination of forged pistons, connecting rods, connecting rod screws, connecting rod bearings, cylinder head gasket and stud.

Visually alone, this set can do it all: Our BAR-TEK® H-Shaft steel connecting rods are riveted in titanium, which is why they shine gold. Matched performance pistons from JE Pistons are available as the Ultra Series. All other parts are also of the highest quality: ARP connecting rod bolts, ACL connecting rod bearings, Cometic MLS head gasket and ARP cylinder head stud.

This is really all you need. These components not only harmonize perfectly with each other, but you also save money in the set compared to purchasing them individually!

Extreme kit for extreme performance

Our kit is obviously not only aesthetically appealing, but is also designed for extreme performance. With this kit you can easily reach up to 1000 HP with your 2.0L TSI! This is because we only pack the best components in our Ultimate Kit and these are also optimally matched to each other.

The JE Pistons piston in this kit features extra coating for extreme performance and comes with High Boost piston pins. At the same time, they are still quite light. This combination is obviously perfect for motorsports. Everything needed for installation is supplied with the piston: bolts, rings and clips.

Our special titanium nitride steel connecting rods are also extremely light and at the same time very robust. Thanks to their surface, they can withstand high pressure loads without any problems. They are machined from solid and have an additional hole for better lubrication of the piston pin (Rifle Drilled). They also come with everything you need for mounting: matching ARP2000 expansion bolts and mounting paste.

These two parts are the stars in the kit and are complemented by high-performance bolts, racing lead bearings and co. As I said, it simply doesn""t work anymore!

High Performance Piston Features:

• Extremely light thanks to the special alloy
• Reinforced for maximum performance
• Also for 82.50 mm bore series
• 21 mm piston pin
• For 2.0L TSI with third generation EA888 type engine
• Installation and hole dimensions attached

Features of the titanium nitride H-shank connecting rod:

• Titanium nitride
• machined from solid material with high resistance
• suitable for extreme power increases of 1000 HP
• extremely light and very stable
• Magnaflux inspected
• 4 pieces per set
• Dimensions: 144 x 21 mm
• Weight for connecting rod with screws only approximately 600 grams
• With oil riser hole for piston pin lubrication (drilled rifle)
• Precisely angled and tested in our factory
• WITH ARP 2000 3/8 expansion screws?

Features of ACL connecting rod bearings:

• Racing bearing, ACL Race
• extra coated
• extra hole for the piston pin

APR Stud Features for Block and Head:

• A MUST for all engines operating with increased boost pressure!
• The most important bolts from the world market leader ARP.
• The studs are made of 8740 chromoly steel and have rounded threads.
• Elastic steel up to 40% stronger than standard bolts.
• All ARP performance bolt kits include ARP compound.
• Additional ARP bolts for bearing blocks

Features of the Cometic MLS head gasket

• Multilayer metal head gasket
• Raw thickness for an optimal compression ratio of 9.5:1

Suitable for all fourth generation 2.0L TSI EA888 engines in Golf 8 etc.

In any case we recommend reinforcing the valve train with our Ferrea valve springs and valves. You can find them below in the accessories.

Suitable for

• Audi A3 / S3 / RS3 8Y | BJ 2020-> STI 2.0L (EA888 Gen.4)
• Seat Formentor VZ 2.0L TSI (EA888 Gen.4) DNF | 310 HP
• Seat Formentor VZ 2.0L TSI (EA888 Gen.4) DNP | 245 HP
• Seat Leon IV (type LK) | BJ 2020-> STI 2.0L (EA888 Gen.4) DNFB | 310 HP
• Seat Leon IV (type LK) | BJ 2020-> 2.0L TSI (EA888 Gen.4) DNFC | 300 HP
• Seat Leon IV (type LK) | BJ 2020-> 2.0L TSI (EA888 Gen.4) DNP | 245 HP
• VW Arteon I (Type 3H) | BJ 2017-> 2.0L TSI (EA888 Gen.4) DNFE | 280 HP
• VW Arteon I (Type 3H) | BJ 2017-> STI 2.0L (EA888 Gen.4) DNFG | 320 HP
• VW Golf VIII (type CD) | BJ 2019-> 2.0L TSI (EA888 Gen.4) DNFC | 300 HP
• VW Golf VIII (type CD) | BJ 2019-> STI 2.0L (EA888 Gen.4) DNFG | 320 HP
• VW Golf VIII (type CD) | BJ 2019-> 2.0L TSI (EA888 Gen.4) DNP | 245 HP
• VW Tiguan II (Type AD1) | BJ 2016-> STI 2.0L (EA888 Gen.4) DNFG | 320 HP
• VW Tiguan II (Type AD1) | BJ 2016-> 2.0L TSI (EA888 Gen.4) DNP | 245 HP
• Skoda Kodiaq I (NS7) | BJ 2017-> 2.0L TSI (EA888 Gen.4) 245 HP | DNP
• Škoda Octavia IV (Type NX) | BJ 2019-> 2.0L TSI (EA888 Gen.4) DNP | 245 HP
